Earthing Accessories
Manufacturer in India
Precigenix manufactures copper earthing rods, clamps, flanges and bonding accessories in Jamnagar, Gujarat — IS:3043 compliant, factory-direct, custom specifications for industrial and commercial electrical systems across India.
PRODUCT
TYPES
Copper Earthing Rods
High-conductivity copper earthing rods in various diameters and lengths for residential, commercial and industrial earthing systems.
- Material: 99.9% copper
- Diameter: 14mm to 40mm
- Length: 1m, 1.5m, 2m, 3m, custom
- Standard: IS:3043
Brass Earthing Clamps
Earthing clamps, strip connectors and pipe clamps in ETP-grade brass for reliable electrical bonding and grounding connections.
- Material: ETP brass / Silicon bronze
- Types: Rod-to-tape, pipe, strip
- Current rating: 100A–600A
- Finish: Tinned / Self-colour
Electrical Bonding Clamps
Equipment bonding clamps for cable armour earthing, panel grounding and structural earthing. Brass and SS available.
- For: Cable armour, bus bars, structures
- Material: Brass / SS304
- Compliance: IEC 60364 / IS:3043
- Custom designs available
Cable Gland Earthing Tails
Copper earthing tails and lead wires used with cable glands to provide armour continuity and equipment bonding.
- Conductor: Stranded copper
- Length: 150mm, 300mm, custom
- Lug type: Ring / Fork
- Rating: Per cable gland size
Earthing Flanges & Adapters
Brass earthing flanges, gland plates and reducers used in electrical panel cable entry for complete earthing system integration.
- Material: Brass (ETP grade)
- Compatibility: All Precigenix cable glands
- Types: Reducing flanges, gland plates
- Finish: Natural / Nickel plated
Chemical Earthing Electrodes
Maintenance-free chemical earthing electrodes for low-resistance earth connections in rocky or dry soil conditions.
- Type: Copper bonded / GI
- Resistance: <1 Ohm maintainable
- Soil types: All — including rocky
- Backfill: Conductive compound supplied
SPECS &
STANDARDS
| Parameter | Specification |
|---|---|
| Material | ETP Grade Copper / ETP Brass / Silicon Bronze |
| Standards | IS:3043, IS:5561, IEC 60364, BS 7671 |
| Earthing Rod Diameters | 14mm, 20mm, 25mm, 32mm, 40mm — custom |
| Earthing Rod Lengths | 1m, 1.5m, 2m, 3m — custom lengths |
| Clamp Current Rating | 100A, 200A, 400A, 600A |
| Surface Finish | Self-colour / Tinned / Hot-dip galvanised |
| Custom Manufacturing | Yes — as per IS drawings or customer spec |
| Supply | Pan India + International Export |
COMMON
QUESTIONS
What is earthing and why is it important?
Earthing (grounding) is the process of connecting the non-current-carrying parts of electrical equipment to the earth. It protects people from electric shock by providing a safe path for fault current to flow to earth, and protects equipment from damage caused by lightning or voltage surges. IS:3043 is the Indian standard for earthing systems.
What is the difference between earthing and grounding?
In Indian electrical engineering, earthing and grounding refer to the same process — connecting electrical equipment to earth for safety. The term 'earthing' is used in IS/BS standards while 'grounding' is the US/NEC term. Precigenix manufactures earthing accessories compliant with IS:3043.
What type of earthing rod is best for rocky soil?
Chemical earthing electrodes are recommended for rocky or high-resistivity soil where conventional copper rods cannot be driven deep enough. They use a conductive compound around the electrode to lower earth resistance without deep driving. Precigenix supplies chemical earthing systems for all soil conditions.
How many earthing accessories does IS:3043 require?
IS:3043 specifies earthing requirements including electrode material, burial depth, earth resistance values, and bonding connections. The exact number of earthing electrodes depends on the installation size, soil resistivity, and target earth resistance (typically below 1 Ohm for sub-stations). Contact our technical team for your specific requirement.
Can Precigenix supply earthing accessories in bulk?
Yes. Precigenix supplies earthing accessories in bulk quantities for infrastructure, construction, industrial and government projects across India. We offer competitive factory-direct pricing with fast lead times from our Jamnagar, Gujarat manufacturing facility.
Get a Factory-Direct Quote from Jamnagar
Share your requirements — specifications, quantity, standards. Our team responds within 24 hours.
