Cable Glands
Manufacturer in India
Precigenix manufactures IP68-rated brass and stainless steel cable glands in Jamnagar, Gujarat — factory-direct, IS & CE certified, custom sizes available. Trusted by Bajaj Electricals, Havells and 50+ brands.
What is a cable gland and what does it do?
A cable gland (also called a cable connector or cable fitting) is a device that secures and seals the end of a cable to electrical equipment — providing strain relief, IP-rated environmental sealing, and safe cable entry. Precigenix manufactures brass and stainless steel cable glands rated to IP66 and IP68, used in electrical panels, junction boxes, motors and industrial enclosures across India and internationally.
CABLE GLAND
TYPES WE MAKE
Single Compression
Cable Glands
For unarmoured cables. Seals cable outer sheath. Available in brass and stainless steel. IP66/IP68 rated. Standard IS/CE certified.
- Threads: PG, Metric, NPT, BSP
- Sizes: PG7 to PG48 / M12 to M63
- Material: Brass (ETP) / SS304 / SS316
- Rating: IP66 / IP68
Double Compression
Cable Glands
For armoured cables. Dual compression on sheath and armour wire. Maximum IP68 sealing for outdoor and hazardous locations.
- Types: BW (brass armour) / CW (steel wire)
- Cable armour: SWA, SWB, AWA, AWB
- Ingress protection: IP68 + IK10
- Standard: IS 12943 / BS 6121
Weather-proof
Cable Glands
For outdoor, wet and marine environments. Neoprene seal with UV-resistant materials. IP68 rated for permanent outdoor installation.
- For: Unarmoured & armoured cables
- Seal: EPDM / Neoprene rubber
- Temperature: -40°C to +120°C
- Rating: IP68
Flame-proof
Cable Glands
For hazardous locations and explosive atmospheres. Zone 1 and Zone 2 rated. Used in oil, gas, petrochemical and mining industries.
- Ex rating: Zone 1 / Zone 2
- IECEx / ATEX compatible designs
- Material: Nickel-plated brass
- Standard: IEC 60079
PG & Metric Thread
Cable Glands
Standard PG thread (PG7–PG48) and metric thread (M12–M63) cable glands for panel, enclosure and machinery cable entries.
- PG sizes: PG7, PG9, PG11, PG13.5, PG16, PG21, PG29, PG36, PG42, PG48
- Metric: M12–M63
- Material: Brass, Nylon, SS
Stainless Steel
Cable Glands
SS304 and SS316 cable glands for food processing, pharma, marine and corrosive environments requiring maximum corrosion resistance.
- Grade: SS304 / SS316 / SS316L
- Finish: Electropolished / Brushed
- Rating: IP68
- Certifications: CE / IS
PRODUCT
SPECIFICATIONS
| Parameter | Specification |
|---|---|
| Material | ETP Brass / SS304 / SS316 / Nickel-plated Brass |
| Thread Types | PG, Metric (M), NPT, BSP, BSPP |
| Size Range | PG7 to PG48 / M12 to M63 |
| Ingress Protection | IP66 / IP68 (1m, 30min) / IP69K on request |
| Impact Resistance | IK10 |
| Temperature Range | -40°C to +120°C |
| Seal Material | EPDM / Neoprene / Silicon Rubber |
| Standards | IS 12943 · BS 6121 · CE · IEC 60529 |
| Surface Finish | Natural Brass / Nickel Plated / Self-colour |
| Cable Type | Unarmoured, SWA, AWA, SWB, AWB, Flexible |
| Custom | Yes — per drawing, material & thread spec |
COMMON
QUESTIONS
What is a double compression cable gland?
A double compression cable gland has two sealing points — one grips the cable outer sheath and the second grips the steel wire armour. This provides IP68 sealing and mechanical retention for armoured cables (SWA, AWA, SWB, AWB types). Precigenix manufactures BW and CW type double compression glands in brass and SS, rated to IS 12943 and BS 6121.
Which cable gland is used for armoured cable?
Double compression cable glands (BW type for brass wire armour, CW type for steel wire armour) are used for armoured cables. They grip both the armour and the outer sheath, providing IP68 sealing and mechanical cable retention. Precigenix supplies all types in brass, stainless steel and nickel-plated finish.
What IP rating do Precigenix cable glands have?
Precigenix cable glands are rated IP66 (dust-tight, strong water jets) and IP68 (dust-tight, water immersion up to 1 metre for 30 minutes). Select models carry IK10 impact protection. All ratings are tested and certified per IEC 60529 standards.
Does Precigenix make custom cable glands?
Yes. Custom cable glands are a core capability at Precigenix. We manufacture cable glands to customer drawings with specific thread types, sizes, materials, IP ratings and surface finishes. Share your drawing or specification and we will send a quote within 24 hours.
Are Precigenix cable glands CE certified?
Yes. Our cable glands are manufactured to IS (Indian Standards) and CE (European Conformity) standards. ETP-grade brass with dimensional assurance and 100% quality control is used on every production batch. We also supply to IS 12943 and BS 6121 standards.
Need Cable Glands? Get a Factory-Direct Quote
Share your specifications — size, thread type, IP rating, quantity. Response within 24 hours from our Jamnagar factory.
